Snapmaker, the company that has made a name for itself in the 3-in-1 printing industry, has introduced a new tool to its arsenal: the Snapmaker 10W laser module. This module is not just a simple addition to the Snapmaker family, but a cutting-edge laser tool that can bring your ideas to life.
The Snapmaker laser module is equipped with the latest laser beam splitters that make a power leap from 5W to 10W. With this increased power, you can work with a wider variety of materials and create more complex projects. The speed of the 10W laser module is also impressive, reaching up to 6000 mm/min while cutting through basswoods as thick as 8mm. In fact, the cutting speed is up to 8 times that of the 1.6W laser module. This module can accomplish laser jobs in no time.
The Fast-axis Collimating (FAC) lenses embedded in the two laser diodes compress the laser spot of each diode before combining the laser beams using the beam-combining technology. This process produces a higher output power and an ultra-fine laser focus (0.05mm × 0.2mm), which allows for higher energy density. The smaller laser focus and higher power provide high-quality laser works with impeccable details.
The Snapmaker 10W laser module is designed with a unique wind channel inside that provides excellent wind pressure. The fumes are blown away as the laser beam cuts into the material, and they are sent directly into the grids of the Laser Engraving and Cutting Platform, which then get channeled out, reducing their interference on laser machining.
Thanks to the triangulation technique, the module is able to measure the thickness of your material by obtaining a few sets of data on the camera and light emitter. It will then adjust itself in Z orientation so that the focal point falls right on the material surface. This means that there's no need for manual material measuring, and you can finish focusing in a few seconds.
The upgraded camera capture process features a wide-angle HD camera that captures your material in one take and lets you get an instant preview in Luban of your laser job on the material. Checking the work area is now completely hassle-free.
The Snapmaker 10W laser module is also equipped with a gyro sensor that ensures the safety of the user and any bystanders. This sensor makes sure that no laser beam comes out if the module is incorrectly installed or deviates from its designated position.
The Snapmaker 10W laser module comes at a cost between $459 and $489. If you're looking for a cutting-edge laser tool that can bring your ideas to life, the Snapmaker 10W laser module is the perfect addition to your toolkit.
