1. Running procedures of drifting fish feed device
( 1) Precautions prior to starting and after quiting
① Check all parts of fish feed drifting pellet making machine, especially the linking screws and also anchor bolts of each area of the puffing chamber, the connecting bolts in between the motor base and also the framework, and the bolt link in between the puffing chamber as well as the structure, and there must be no looseness;
② Manually rotate the primary shaft, at this time, there ought to be no massaging noise in the fish feed drifting pellet making maker puffing tooth cavity;
③ Begin the feeding auger of fish feed floating pellet making device, inspect its stepless high-speed efficiency, and require typical procedure;
④ Examine and clean the water as well as gas courses prior to beginning the fish feed drifting pellet making equipment, and all filters require to be cleansed;
⑤ Before beginning the fish feed floating pellet making maker, check whether the circuitry of the electric control part is proper, whether the turning of each motor is appropriate, as well as whether the control is trustworthy;
⑥ After the fish feed drifting pellet making device is stopped, you have to use high-temperature gloves, quickly remove the discharge mold, and also right away clean it while it is hot, and also start the major motor to clear the product gathered in the puffing tooth cavity. When the corn is blown, soybean powder ought to be included The product is rinsed clean;
⑦ Take notice of safety when dumping the machine, as well as do not stand in front of the equipment to avoid risk caused by residual stress in the fish feed drifting pellet making machine tooth cavity;
⑧ After the fish feed floating pellet making maker is running usually, it shall not be shut down at will.
Related post: fish feed mill plant cost
( 2) Power on
① Prior to starting the fish feed drifting pellet making machine, check the fasteners, and also there have to be no looseness;
② Ensure the typical supply of steam and also water;
③ Guarantee that the power supply as well as electric home appliances are regular;
④ Open the steam valve, pre-heat the floating fish pellet maker blowing chamber, the temperature is about 100 degrees;
⑤ Beginning the fish feed drifting pellet making maker: begin the conditioner, start the feeding auger, when there is material draining from the outlet of the conditioner, start including vapor to the conditioner.
A small amount of water is added, and also the material is fed right into the puffing dental caries at the same time. After the material is squeezed out by fish feed drifting pellet making device, the puffing result as well as moisture of the product are readjusted.
Related post: https://www.richipelletmachine.com/fish-feed-mill-plant-cost/
( 3) Downtime
After the fish feed floating pellet making machine manufacturing pertains to an end, it needs to be quit. The stop series is: feeding auger and also conditioner. After that wait till the shown worth of the main engine current on the electric control cupboard comes to be the no-load existing value, after that quit the primary motor as well as the oil pump motor.
( When the corn is puffed, about 25 kg of soybeans need to be fed into the bypass feeding port of the first area of the blowing dental caries. To clean the recurring corn material in the puffing dental caries, and then quit the primary motor to avoid the fish feed floating pellet making device from blocking), after that swiftly disassemble the puffing dental caries of the tail area for cleansing.
After cleansing, use oil to the inner wall of the main shaft and also screw head (After feeding grease), re-install it and await the following boot;
When you see that the product level indication on the silo suggests that the product degree has actually gotten to the lowest level, begin to get ready for closure. Right now, do not quit the feeding auger as well as conditioner, and stop feeding when the primary fish feed floating pellet making maker present declines to the no-load present auger as well as conditioner.
Related post: poultry feed plant price
2. Procedure sequence of floating fish feed machine
( 1 )When puffing soybeans, the two areas at the inlet end of the puffing cavity are single screw heads, as well as the 3 areas at the electrical outlet end are geared up with dual screw heads.
Initially, include vapor to the jacket to preheat the puffing cavity to about 100 degrees, as well as placed the screws on the puffing cavity at the tail area. After the plug is tightened up, loosen it for 3-4 turns, and after that tighten the screw plug to repair the screw plug prior to feeding.
By managing the stepless high-speed system of the feeding auger, the feeding rate is from slow-moving to quickly, and also the feeding speed is from small to big. After the soybean meal is expelled from the screw plug hole, add the cover to enter the typical manufacturing, as well as set up the screw connects with different apertures to obtain soybean meal with various yields and excellences.
By setting up the conelike pressure rings of different sizes, the suggested temperature level of the four-section (discharge end) puffing dental caries is 130-140 levels. It is advised that the sieve of the crusher utilized for crushing soybeans should have a diameter of 3-4.
( 2 )When extruding powdery feed by fish feed floating pellet making machine, the squeezing out screws in the extruding dental caries are all solitary screw heads, include heavy steam to the coat to preheat the blowing tooth cavity to about 80 levels, and go into the fish feed floating pellet making machine and also vapor consistently satiated and solidified powder.
Concerning 18%, this have to be performed in the feed conditioner, as well as the feed quantity is managed by the stepless speed regulating device from little to huge. Note that the analysis of the ammeter of the main motor need to not surpass the ranked current of the major engine of fish feed floating pellet making equipment.
Beware of overloading the electric motor and squeezing out fine-grained products. When the temperature level of the extruding chamber at the discharge end is regulated to an suitable level by configuring conelike pressure rings with various sizes.
The above is the principle, framework as well as operating treatments of the fish feed drifting pellet making machine introduced by Richi Equipment. In quest of crispy taste as well as excellent look, suppliers commonly add a raising agent (or baking powder), which consists of a certain amount of aluminum components, and creates gas when heated throughout cooking or frying, and also the raising agent is inside the food.
