High-moisture product organic fertilizer quickly organic plant food pellet making maker is additionally called wet mixing tooth organic plant food pellet making device, inner turning stirring tooth granulator, this granulator is a plant food pellet making device
Wet natural fertilizer granulator is widely made use of in the granulation of organic plant food. Because of the high granulation price, secure procedure, sturdy as well as resilient equipment, lengthy service life, and stable base layout, it runs more smoothly, so it is picked as the suitable item by the majority of individuals.
The requirements as well as designs of the wet organic plant food pellet making equipment are 400, 600, 800, 1000, 1200, 1500 and also other specs, and can additionally be tailored according to user requirements.
Related post: organic fertilizer making machine
1. Working principle of organic fertilizer pellet making machine
The stirring tooth organic plant food pellet making maker makes use of the mechanical stirring pressure of high-speed turning and also the resulting aerodynamic pressure to make the great powder product continually understand the procedures of mixing, granulation, spheroidization, and densification in the equipment, so regarding accomplish the objective of granulation.
The particle form is round, the fragment dimension is usually in between 1.5 ~ 4 mm, and the granulation rate of 2 ~ 4.5 mm particles is ≥ 90%. The fragment size can be changed appropriately by the product blending amount and also the spindle speed. Usually, the reduced the blending quantity, the faster the rate. High, the smaller sized the bits, and also vice versa the larger the fragments.
The stirring tooth natural plant food pellet making maker processes the fermented natural basic materials into granules. Compared to the disc granulator, the yield is greater, the granules are uniform, smooth, high in stamina and also low in water material. The temperature after forming is about 30 levels.
After the fermented raw materials are shattered, they are blended with a mixer so that the dampness material of the product is in between 35% and 40%. After getting in the natural plant food pellet making maker, round fragments can be refined.
It takes advantage of the truth that natural fertilizer raw materials are decorated with each other under a specific effect, as well as the particles generated are rounded, smooth and high in strength. Needed ingredients and adhesives can additionally be added to more improve product top quality.
Related post: https://www.richipelletmachine.com/organic-fertilizer-pellet-making-machine/
The organic fertilizer raw materials appropriate for the stirring tooth natural plant food making equipment include: livestock and fowl manure, garden compost plant food, green manure, sea plant food, cake plant food, peat, soil as well as assorted plant food, 3 wastes, bacteria and also local solid waste, and so on.
The qualified granulation price of this natural plant food pellet making equipment is as high as 90% or more, and it appropriates for a range of different formulas. This equipment is most suitable for straight granulation of natural plant food after fermentation, leaving out the drying out procedure as well as greatly lowering the manufacturing cost. For that reason, the mixing tooth natural plant food pellet equipment is favored by the majority of individuals.
The natural plant food granulator machine produced by our firm remains in short supply, power conserving and also environmental protection are credible!
2. The scope of application of organic plant food pellet making machine
Grass charcoal, sludge, animals manure, lignite, fermented straw, and so on are utilized as basic materials for natural fertilizer manufacturing and granulation. The above data are based upon peat, animals manure, and also fermented straw, and various other resources undergo speculative information.
3. Installment of plant food pelletizer maker.
( 1 ) Setup: The organic fertilizer pellet making machine requires to put concrete foundation before setup to facilitate the transfer of finished products, and also solution and also bonded the organic plant food pellet making equipment and also the embedded iron together to prevent the granulator from moving; network steel can likewise be used to bond the framework.
Place the granulator on the bottom structure; it is additionally possible to dig a pit for product transport.
Related post: tofu cat litter factory
( 2 )Commissioning: After the natural plant food pellet making machine is mounted, it is needed to examine whether the parts of the granulator are attached. Then carry out the no-load test run. Throughout the trial run, there must be no massaging or touching, no abnormal noise, and also no resonance.
The temperature of each bearing of the natural plant food pellet mill need to increase progressively. At the end of the test run, the temperature level of each element need to not be greater than 50 ℃. There need to be no serious deterioration. When the trial run remains in regular production, it has to be fed uniformly.
( 3) Upkeep of organic plant food pellet making maker:
a. The bearing is lubricated when per change. The lubricating oil type is No. 3 calcium-based oil lubricating oil, and also the filling quantity is 1/3 ~ 1/2. The brand-new lubricating oil need to be replaced consistently. The organic plant food pellet making device bearing must be cleaned when replacing.
b. Lubricating oil have to be included before the reducer is utilized. The lubricating oil is usually HJ40-50 mechanical oil, and HL20-30 equipment oil can also be made use of. The oil level of the lubricating oil should be within the range shown by the round oil mark on the maker base.
After the first refueling procedure for 100 hrs, the new oil needs to be replaced, as well as every six months afterwards, and also the oil needs to be cleaned when altering the oil.
( 4) Putting on components:
a. triangular belt
b. Bearings
c. Stirring head
4. Guidelines for use plant food pelletizer
Before starting the organic plant food pellet making equipment, examine whether the link of the equipment hangs, and pay special interest to whether the mixing head is loose.
The natural fertilizer pellet making equipment is strictly banned to start with tons.
When the natural plant food making device is switched off, stop feeding initially, as well as switch off the power after the material in the machine is completely discharged. Long-lasting shelving is not necessary to get rid of the products in the body to avoid sticking.
It is purely restricted for iron blocks, rocks, wooden sticks as well as other sundries to go into the device to stop damages to the maker.
When beginning the major electric motor, first take note of the tightness of the V-belt. If the V-belt slips when it is as well loosened, the natural fertilizer pellet making maker will certainly not rotate typically.
If it is also limited, the service life of the organic fertilizer pellet making equipment bearing and also the V-belt will be affected. After that inspect whether the turning direction is appropriate, if it turns in the contrary direction, stop and also adjust right away.
